Particle-Wave Duality Physics
A free science worksheet ready for your classroom. Open in Kuraplan to grab the print-ready PDF, customize it for your students, or generate a fresh version in seconds.

Particle-Wave Duality Physics
📚 Part 1: Photoelectric Effect & Energy Conversions
1. The work function of a metal is the minimum energy needed to remove an electron from its surface. Which of the following correctly describes threshold frequency?
The maximum frequency that can cause photoemission
The minimum frequency needed to emit photoelectrons
The frequency that gives maximum kinetic energy
The frequency of emitted electrons
2. The photoelectric equation is hf = φ + Ek(max). If a photon of frequency 8.0 × 10¹⁴ Hz hits a metal with work function 2.1 eV, calculate the maximum kinetic energy of emitted photoelectrons. (h = 6.63 × 10⁻³⁴ J·s, 1 eV = 1.6 × 10⁻¹⁹ J)
3. Convert the following energy values:
a) 3.2 eV = _____________ J
b) 9.6 × 10⁻¹⁹ J = _____________ eV
4. In a photoelectric experiment, the stopping potential is 1.5 V. What is the maximum kinetic energy of the photoelectrons?
⚡ Part 2: Energy Levels & Line Spectra
5. In a fluorescent tube, mercury atoms are excited when electrons collide with them. Explain the difference between excitation and ionisation:
6. An electron in a hydrogen atom drops from energy level E₂ = -1.51 eV to E₁ = -3.40 eV. Using hf = E₁ - E₂, calculate the frequency of the emitted photon.
7. Which of the following statements about line spectra are correct? (Select all that apply)
Each element produces a unique line spectrum
Line spectra show that electrons exist in discrete energy levels
All atoms produce identical line spectra
The colours correspond to specific photon energies
🌊 Part 3: Wave-Particle Duality
8. The de Broglie wavelength equation is λ = h/mv. Calculate the de Broglie wavelength of an electron moving at 2.0 × 10⁶ m/s. (mass of electron = 9.11 × 10⁻³¹ kg)
9. Electron diffraction experiments show that electrons behave like waves. What happens to the diffraction pattern when the momentum of electrons increases?
The diffraction rings become larger
The diffraction rings become smaller
The pattern disappears completely
The pattern remains unchanged
10. Explain how the photoelectric effect demonstrates the particle nature of light, whilst electron diffraction demonstrates the wave nature of matter:
Extension Challenge: Research how peer review helped validate quantum theory. Why was it important for Einstein's photoelectric effect explanation to be reviewed by other scientists?
