Textiles in Bridge Engineering

Name:

Date:

🔍 Part 1: Understanding Textile Weaves and Bridge Engineering

1. Which type of textile weave is most commonly used in composite materials for bridge construction?

Plain weave

Twill weave

Satin weave

All weaves are equally suitable

2. What is tensile strength in engineering?

How much a material can compress before breaking

How much pulling force a material can withstand before breaking

How much a material can bend before snapping

How heavy a material is per square metre

3. Which materials are commonly used in composite textiles for bridge reinforcement? (Select all that apply)

Carbon fibre

Fibreglass

Cotton

Aramid fibres

4. Complete the sentence: Composite textiles are used in bridges because they provide _____________ whilst remaining _____________ than traditional materials.

a) high strength, lighter

b) low cost, heavier

c) flexibility, more expensive

d) waterproofing, weaker

🧪 Part 2: Practical Investigation and Data Recording

5. Hypothesis: Before testing, which weave combination do you predict will have the highest tensile strength? Explain your reasoning.

6. Record your tensile strength test results:

Sample 1 (Plain weave): Broke at _______ grams

Sample 2 (Twill weave): Broke at _______ grams

Sample 3 (Combined weave): Broke at _______ grams

Best performing sample: _________________

7. Analyse your results: Why do you think certain weave patterns performed better than others in your tensile strength tests?

8. How might engineers use your findings when designing textile reinforcements for real bridges? Give two specific examples.

Example 1:

Example 2:

💡 Part 3: Application and Evaluation

9. Explain why composite textiles might be chosen over traditional steel reinforcement in some bridge construction projects. Consider at least two factors.

10. A bridge engineer needs to reinforce a suspension bridge cable. Based on what you've learned, what type of textile reinforcement would you recommend and why?

11. Reflection: How has this investigation changed your understanding of the role of textiles in engineering? What surprised you most?
